Used in the following Vacumaid central vacuum models:
P125/MKX
P225/MKV before February 1999
P325 / MKIII
H1 / MKI before January 1994.
Also used by other manufacturers including AirVac, Beam, Eureka, Hayden, MD, Nutone, Power Star, and Walvac
| 115334 Basic Model Data | |
| Volts: 120 | Discharge: Tangential |
| Fan Stages: 2 | Fan Diameter: 7.2 Inches |
| Type: Bypass | Bearings: Double Ball |
| 115334 General Motor Performance | |
| Rating Watts: 1400 | Air Watts: 384 |
| Sealed Vacuum: 110.0 Inches | Max Airflow: 102.7 CFM |
| 115334 Motor Performance at Operating Orifice 3/4″ | |
| Vacuum: 57.7 Inches | Airflow: 56.9 CFM |
| Input Watts: 1332 | Input Amps: 12 |
| Air Watts: 384 | Motor Speed: 17,400 RPM |
Motor 115334 is a replacement motor for:
- AirVac 110
- Beam 75
- Beam 80
- Beam 95
- Beam 99
- Beam 153
- Beam 154
- Beam 183
- Beam 190
- Beam 253
- Beam 254
- Beam 259
- Beam 284
- Beam 294
- Beam 297
- Beam 297S
- Beam 297SP
- Beam 297C
- Broan CV-16
- Broan V16C
- Budd 0704
- Fasco 851
- Hayden SV36
- NuTone 350
- Pullman-Holt 105
- Vacuflo 26
- Vacuflo 99
- VacuMaid P125
- VacuMaid P225
- VacuMaid P325
- Wal Vac 236
- Wal Vac 836
- Whirlpool FB7700XSO
