The MB117549-12 was used in the following VacuMaid central vacuum models:
P125P
P225 / MKV since May 1997
S2000 since May 1997.
S2600 after June 2006.
S3200 since July 1997.
SR50 – This motor replaces the MB117467 used in the SR50.
Also used by other manufacturers including Beam, Budd, Electrolux, Imperium, Nutone, Silent Master, and Vacuflo.
Replacement for 117478, 117467, 117129, 116465, 116467.
Basic Model Data | |
Volts: 120 | Discharge: Tangential |
Fan Stages: 2 | Fan Diameter: 7.2 Inches |
Type: Bypass | Bearings: Double Ball |
General Motor Performance | |
Rating Watts: 1500 | Air Watts: 495 |
Sealed Vacuum: 124.6 Inches | Max Airflow: 115.8 CFM |
Motor Performance at Operating Orifice 3/4″ | |
Vacuum: 67.6 Inches | Airflow: 61.7 CFM |
Input Watts: 1398 | Input Amps: 12.4 |
Air Watts: 490 | Motor Speed: 17,410 RPM |
